4 channels DVR, 5-in-1, up to 8MP recording, H.265Pro+, 4x HDD up to 10TB, HDMI, VGA and CVBS outputs, 16In/4Out, RS-232, RS-485

Specifications:
- Video compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Analog video input: 4-ch (1.0Vp-p, 75 Ohm) - supporting coaxitron connection
- CVBS: NTSC/PAL
- HD-TVI: 8MP, 5MP, 4MP, 3MP 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25
- AHD: 5MP, 4MP, 1080p25, 1080p30, 720p25, 720p30
- HD-CVI: 4MP, 1080p25, 1080p30, 720p25, 720p30
- IP video input
- Normal mode: 4-ch (up to 8-ch)
- Resolution: up to 8MP (support H.265+/H.265/H.264+/H.264 IP cameras)
- Audio
- Input: 4-ch, RCA (2.0 Vp-p, 1 KOhm)
- Output: 2-ch, RCA (Linear, 1KOhm)
- Two-way audio: 1-ch, RCA (2.0 Vp-p, 1 KOhm) (using the audio input)
- Compression: G.711u, 64Kbps
- Vídeo Output
- VGA/HDMI1: 1 canal, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- HDMI2: 1 canal, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- CVBS: 1 canal, BNC (1.0 Vp-p, 75 Ohm), PAL: 704 × 576, NTSC: 704 × 480
- Encoding resolution (main stream): 8MP, 5MP, 4MP, 3MP, 1080p, 720p, WD1, 4CIF, VGA, CIF
- Frame Rate (main stream): 8MP@8fps, 5MP@12fps, 4MP@15fps, 8MPLite@15fps, 3MP@18fps, 1080p, 720p, WD1, 4CIF, VGA, CIF@25fps (P)/30fps (N) (P)/30fps
- Remote connections: 128
- Network protocols: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF, SNMP
- Interface
- SATA: 4x SATA, up to 10TB
- eSATA: supports
- Network: 2x RJ-45 10M/100M RJ45 10M/100M/1000M self-adaptive Ethernet interface
- USB: 2x USB 2.0 (front panel); 1x USB 3.0 (rear panel)
- Serial: RS-232, RS-485 (half-duplex), Keyboard
- I/O Alarms: 16 In/4 Out
- Power supply: 100 a 240VAC
- Consumption (without HDD): max. 35W
- Working temperature: -10ºC to 55ºC (+14°F to +131°F)
- Working humidity: 10% to 90%
- Dimensions: 445 × 390 × 70 mm (17.5 × 15.4 × 2.8 inch)
- Weight (without HDD): approx. 5 kg (11.0 lb)
